ITFlow IT Documentation and MSP Platform

This is a repackaged open source software product wherein additional charges apply for cloudimg support services.

ITFlow is a widely used open source IT documentation and business management platform built for managed service providers and internal IT teams. It gives you one authoritative place to record every client along with their contacts, locations, assets, networks and credentials, then runs the work around them: tickets with email parsing and a client portal, projects, invoices, quotes, recurring billing, expenses, and domain and SSL certificate expiry tracking. This image delivers ITFlow 26.07 with its full stack configured and hardened, so you have a working platform within minutes of launch, eliminating hours of manual dependency installation, web server configuration, database setup, TLS provisioning and hardening that a self managed deployment requires. The current release available is ITFlow 26.07.

Application Stack

ITFlow is a PHP application running on PHP 8.3 with OPcache and the mysqli, intl, curl, mbstring, gd and xml extensions, served by Apache with libapache2-mod-php. MariaDB provides the database over a local unix socket. The scheduled jobs (mail queue, ticket email parser, domain and certificate refresher) run every five minutes from a systemd timer using the PHP command line, never from a public web endpoint.

No Credential Ships In The Image

ITFlow derives its encrypted credential vault master key from the administrator password, so the account must be created with its final password rather than rotated afterwards. This image therefore installs ITFlow on your own instance at first boot using ITFlow's own official installer, with a database password, an administrator password and a TLS certificate all generated uniquely for that instance. The administrator password is written to a root only file and its location is shown in the login banner. There is no default credential to find, and none to change.

Served Over HTTPS, Hardened Beyond A Stock Install

The platform is served over HTTPS from the moment it starts, which matters for a product that stores your clients' passwords and TOTP secrets in an encrypted vault. The certificate is self signed and generated for your instance, so your browser asks you to accept it the first time; the paired guide walks through installing a certificate from your own certificate authority or from Let's Encrypt. The image goes further than a stock install: the web installation wizard is deleted rather than merely disabled, PHP execution is blocked in the customer writable document and attachment tree, and the vendored library tree and command line installers are denied from the web.

Dedicated Data Volume

A dedicated data volume holds the MariaDB database and your uploaded client documents, ticket attachments and invoice PDFs, keeping customer data independent of the operating system disk so it can be snapshotted and grown on its own.

cloudimg Support

24/7 technical support by email and chat. Help with ITFlow deployment, TLS certificate installation including Let's Encrypt, mail and ticket email parsing setup, client portal configuration, credential vault and TOTP usage, invoicing, quoting and recurring billing, domain and SSL certificate expiry tracking, upgrades, backup and restore, and MariaDB administration.

Use Cases

Run an MSP practice management and IT documentation platform in your own VPC for data residency or compliance. Track clients, assets, networks and an encrypted credential vault; route inbound email into tickets with a client portal; and manage projects, quotes, invoices and recurring billing from one self hosted application.
